Q235B features a nominal yield strength of 235 MPa and ultimate tensile strength of 370–500 MPa, serving as the global standard for low-to-medium bay selective and light-duty shelving applications. Q355B is a micro-alloyed structural steel boasting a minimum 355 MPa yield strength. It is selected for high-bay uprights exceeding 10 meters, heavy-duty automotive mold racks, cantilever upright columns, and warehouses situated in high-intensity seismic design zones where exceptional load-to-weight performance is non-negotiable.

Standard commercial racks often utilize basic solvent-based dip paint that blisters and peels in warm, humid coastal air. Every HEDA Shelves component undergoes an automated multi-stage pre-treatment: alkaline degreasing, hot water rinsing, acid rust removal, surface conditioning, and zinc phosphate bath conversion. This creates a crystalline barrier before electrostatic epoxy-polyester powder application (60–80 µm dry film thickness). For harsh cold rooms or marine salt spray zones, full hot-dip galvanization is available.

Yes. Our structural engineering department performs finite element stress simulations (FEA) calibrated to seismic acceleration variables ($S_s, S_1$) and ground soil classes according to UBC-97, IBC, AS 4084, and Eurocode 8. Based on calculated lateral shear forces and moment overturning vectors, we engineer heavy-duty footplates, increased floor anchor bolt gauges, reinforced diagonal K-bracing, and heavier upright column wall thicknesses.

To prepare a free precision 2D AutoCAD and 3D architectural rendering, we require: (1) Architectural floor plan indicating clear height to underside of roof trusses, column grids, dock doors, and fire sprinkler clearances; (2) Pallet specifications including width, depth, overall height, and maximum gross loaded weight; (3) Existing or planned Material Handling Equipment (forklift brand, mast model, collapsed mast height, maximum reach, and minimum turning radius); and (4) Operational daily pallet throughput.

In compliance with European standard EN 15512 and the American RMI MH16.1 code, maximum vertical elastic deflection of horizontal pallet beams under full uniformly distributed load (UDL) must not exceed $L/200$ (where $L$ is the clear span distance between upright columns). For sensitive automated crane applications or radio shuttle rails, deflection is constrained to $L/400$ to maintain automated sensor alignment.

Shipments dispatch from the international deepwater port of Nansha/Guangzhou. Direct ocean transit to major Southeast Asian ports takes only 2–5 days (Vietnam, Philippines) and 5–8 days (Singapore, Thailand, Malaysia, Indonesia). To minimize ocean freight charges per pallet position, upright frames are flat-packed or pre-bolted with nesting, while beams are banded on heavy wooden runners to maximize container cubic weight up to 26–27 metric tons per 40HQ.
