Featured Engineering Case

Global Execution: Medium Duty Storage Shelving Solutions

Designed to bridge the gap between light manual picking and heavy pallet storage. Guangzhou Heda Shelves Co., Ltd. supplies high-precision cold-rolled steel shelving engineered for cartons, tote bins, and multi-tier picking aisles.

Building Supplies & Distribution Ecuador Project

Medium Duty Shelving System for General Storage Warehouse

This project required an efficient, modular layout to accommodate diverse building hardware and general store inventory. Guangzhou Heda Shelves Co., Ltd. designed a multi-bay configuration using cold-formed step beams, durable steel decking panels, and adjustable pitch levels to allow flexible SKU reorganization without specialized tools.

Load Capacity 200 - 800 kg / Level

Surface Finish Electrostatic Powder Coated

Material Grade High-Grade Q235B Cold Rolled Steel

Compliance Standard CE & ISO 9001:2015 Certified

All upright frames were pre-treated with pickling and phosphating before electrostatic coating to resist ambient warehouse moisture and industrial wear, ensuring structural reliability under high-frequency daily operation.

Engineering Credentials & Verification

Client Verification & Project Reviews

Explore on-site implementation photography and verified operational reviews demonstrating structural integrity, installation accuracy, and international dispatch reliability.

Client operational verification and shelving assembly

Aisle Clearance & Picking Optimization

Systematic aisle planning ensuring smooth manual carton sorting and ladder cart integration.

Load Deflection Verification

Uniformly distributed load testing across steel decking panels according to international safety thresholds.

Warehouse storage layout completed handover

Finished Bay Handover

Complete multi-tier storage layout validated for high SKU selectivity and quick stock turnover.

Industrial warehouse shelving implementation

Component Alignment Accuracy

Laser-guided column alignment ensuring absolute vertical plumb across interconnected shelving bays.

Frame Safety Locking Inspection

Safety pin and connector verification preventing accidental dislodgement during rapid material handling.

Modular Expansion Readiness

Adaptable frame design allowing future height extensions and shelving-supported catwalk upgrades.

Multi-Level Storage Integration

Synchronized implementation of medium duty shelving with secondary picking platforms.

Structural Bracing Review

Rigid cross and diagonal bracing installed to guarantee side-sway stability under maximum loads.

Turnkey Site Commissioning

Final technical audit and load certification provided by Guangzhou Heda Shelves Co., Ltd. specialists.

Commercial warehouse storage verification

High-Density Manual Sorting

Multi-compartment storage layouts reducing picker transit time across industrial parts warehouses.

Baseplate Anchor Verification

Heavy-duty anchor bolts secured directly into concrete slab foundations for seismic durability.

Warehouse Operational Handover

Complete bay labeling and shelf-load indicator plaques fixed in compliance with international norms.

Comprehensive storage installation assessment

Protective Coating Quality Audit

Thickness and adhesion verification of thermosetting powder coating against scratch and impact.

Precision Roll-Formed Profiles

High dimensional accuracy ensuring rapid, boltless beam adjustments on 50mm increments.

Complete Client Acceptance

Client satisfaction sign-off on timely container delivery and seamless assembly precision.

Custom Engineered Medium Duty Shelving for Your Facility

Guangzhou Heda Shelves Co., Ltd. provides comprehensive engineering consultations, free CAD floor plans, and factory-direct pricing for international warehouse projects.
